LTC3819EG LTC3819 - 2-Phase, High Efficiency, Step-Down Controller for Sun Server CPUs



LTC3819EG LTC3819 - 2-Phase, High Efficiency, Step-Down Controller for Sun Server CPUs

The best product you are looking for is "LTC3819EG LTC3819 - 2-Phase, High Efficiency, Step-Down Controller for Sun Server CPUs". This product is available and ready to be purchased. Get attractive discounts every time you shop in our store (aliexpress.com). Aliexpress also provides a coupon of $ 3 for the first buyer to shop there. don't forget to bookmark our store page so you can go shopping again anytime..

Product Details

Name	Details
Buy now just	US $4.35
Discount
Product id	1000004627006
Vendor	POCCIO Official Store
Category	Consumer Electronics - Video Games

Buy Now On Aliexpress

Video Games

Video Games

Description :

Features and Benefits

• Output Stages Operate Antiphase Reducing Input and Output Capacitance Requirements and Power Supply Induced Noise
• Dual Input Supply Capability for Load Sharing
• 5-Bit SUN CPU VID Code:
•   VOUT = 1.025V to 1.4125V
• ±1% Output Voltage Accuracy
• True Remote Sensing Differential Amplifier
• Power Good Output Voltage Monitor
• Supports Active Voltage Positioning
• Current Mode Control Ensures Current Sharing
• OPTI-LOOP® Compensation Minimizes COUT
• Three Operational Modes: PWM, Burst and Cycle Skip
• Programmable Fixed Frequency: 150kHz to 300kHz
• Wide VIN Range: 4V to 36V Operation
• Adjustable Soft-Start Current Ramping
• Internal Current Foldback and Short-Circuit Shutdown
• Overvoltage Soft Latch Eliminates Nuisance Trips
• Available in 36-Lead Narrow (0.209) SSOP Package



Product details



The LTC3819 is a 2-phase, VID programmable, synchronous step-down switching regulator controller that drives two N-channel external power MOSFET stages in a fixed frequency architecture. The 2-phase controller drives its two output stages out of phase at frequencies up to 300kHz to minimize the RMS ripple currents in both input and output capacitors. The 2-phase technique effectively multiplies the fundamental frequency by two, improving transient response while operating each channel at an optimum frequency for efficiency. Thermal design is also simplified.   An operating mode select pin (FCB) can be used to select among three modes including Burst Mode® operation for highest efficiency. An internal differential amplifier provides true remote sensing of the regulated supply’s positive and negative output terminals as required in high current applications.   The RUN/SS pin provides soft-start and optional timed, short-circuit shutdown. Current foldback limits MOSFET dissipation during short-circuit conditions when the overcurrent latchoff is disabled. OPTI-LOOP compensation allows the transient response to be optimized for a wide range of output capacitors and ESR values.

Applications



• Sun™ Server CPU Supply
